Description
DESCRIPTION
The RS Series delivers EAW signature performance in a portable and lightweight wooden enclosure. Each enclosure in the series is first designed around the latest breed of touring grade HF and LF transducers. The intelligent features of the series include EAW Focusing which provides unmatched musical clarity and tonal accuracy. Pattern control of the RS Series is further enhanced by the unique, constant directivity HF horn; a design theory first proven in our legendary MK Series, a series born from the audio performance needs of stadiums throughout the world.
SPECIFICATIONS
- Frequency Response
- 55 Hz – 20 kHz
- Max SPL
- 135dB
- Operating Mode
- Bi-Amp LF, HF
- Subsystem
- 12 in Cone, 2.5 in Voice Coil
- 1.4 in Voice Coil Compression Driver, 1 in Exit
- Nominal Beamwidth
- 90° Horizontal
- 60° Vertical
- Power Handling
- 1500W
- Connections
- IEC Power Connector
- XLR Input/Thru
- Dimensions
- Height: 25.9 in
- Width: 14.5 in
- Depth: 15 in
- Weight
- 42lb (19kg)
