Description
Analog Bassline Synthesizer with Ribbon Controller, 16-step Sequencer, 3 x Self-tuning Oscillators, Slide Function, MIDI Input, and Sync I/O
Aggressive sounds that stand up to the drums; fat sounds that support the rhythm; funky sounds that generate a groove – the volca bass is an analog bassline groove box that has what you need for a wide range of bass lines.
Although simple in structure, the analog sound engine has an unmistakable presence with subtle nuances that cannot be reproduced by a digital simulation; it’s a great choice for acid house and many other styles of music. The step sequencer distilled from the Electribe is not only visually intuitive; it’s also a powerful way to generate “free form” bass loops that will stimulate your inspiration.
Features and specs:
Keyboard
Multi touch Keyboard / step key
Synthesizer
Type
Analog synthesis
Structure
3VCO, 1VCF, 1VCA, 1LFO, 1EG
VCO Wave
Saw, Square
VCF
Cutoff, Peak, EG Int
VCF Type
Low Pass Filter, 12 db/oct
VCA
EG on/of, Sustain on/off
LFO
Rate, Int, Target (Amp, Pitch, Cutoff), Wave (Triangle, Square）
EG
Attack, Decay/Release, Sustain
Sequencer
Number of parts
3
Number of Steps
16
Number of Recording Patterns
8
Connectors
Audio Output
Headphones (3.5mm stereo mini jack)
Sync
Sync In (3.5mm monaural mini jack, Maximum input level: 20V)
Sync Out (3.5mm monaural mini jack, Maximum Output level: 5V)
MIDI
In
Power
Battery Life
Approximately 10 hours (using alkaline batteries)
Power supply
AA alkaline battery ×6
AA nickel-metal hydride battery ×6
AC adapter “KA-350” (optional)
Others
Accessories
AA alkaline battery ×6 (for verifying operation)
Options
AC adapter “KA-350”
Dimensions
(W x D x H)
193 × 115 × 46 mm / 7.61 x 4.54 x 1.82 inches
Weight
370 g / 0.82 lbs (Excluding batteries)
