LR Baggs Venue DI Acoustic Guitar Preamp/DI

Description

LR Baggs Venue DI Acoustic Guitar Preamp/DI

We created the Venue DI so you can travel light, set up fast, and sound incredible anywhere you plug in. The Venue DI gives you complete control by combining a full-isolation DI output, 5-band EQ with adjustable low & hi-mid bands, variable clean boost, and chromatic tuner all in one acoustic pedal. With its all-discrete signal path, hi-graded semiconductors, and exclusive use of audiophile grade film capacitors, the Venue DI is on par with the world’s elite preamps and provides a studio quality sound for the stage.

Highlights

• Adjustable gain for both passive and active pickups
• 5 band EQ with tunable low-mid and high-mid bands
• Garret Null notch filter for effective feedback control
• Phase inversion for best sound and feedback control
• Full chromatic tuner with footswitch mute/tune function
• Adjustable volume boost footswitch
• Full isolation audio transformer couple DI
• 4 segment clip meter to visually optimize gain setting
• 4 segment battery status gauge
• XLR and ¼” outputs
• Series FX loop (separate jacks for send and return)
• Works with 9V battery or DC adapter (not provided)

Specifications

• Type:Acoustic Guitar Preamp
• EQ:Bass, Low Mid, Hi Mid, Treble
• Inputs:1 x 1/4″ (instrument), 1 x 1/4″ (return)
• Outputs:1 x 1/4″, 1 x XLR (DI out), 1 x 1/4″ (send)
• Power Source:9V DC power supply (sold separately)
• Height:1.5″
• Width:7.6″
• Depth:7.5″
• Weight:2.2 lbs.
• Manufacturer Part Number:VENUE DI

Please feel free to reach out to our knowledgeable sales staff with any additional questions!
